Features
1.Clampthe tubing use corresponding dies, jaw set.23/8" jaws are offered.
2.Torquecontrol valve may be equipped (optional).
3.Chooseand buy lengthening guide pole assembly, the backup tong can clamp the tubingbody,
4.TorqueControl System may be equipped (optional).
Remark:The backup tong of Model XQ114/6C needn’t to change any parts for2 7/8"、 3 1/2"、41/2"tubing.
Model | XQ114/6B | XQ114/6C | XQ114/9 |
Range of Master Tong | Ф73-114 2 7/8”-4 1/2” | Ф73-114 2 7/8”-4 1/2” | Ф60-114 2 3/8”-4 1/2” |
Range of Backup Tong | Ф73-141.5 2 7/8”-5 9/16” | Ф73-141.5 2 7/8”-5 9/16” | Ф73-141.5 2 7/8”-5 9/16” |
High Gear Rated of Torque | 1500 N.m 1106 ft.lbs | 1650 N.m 1210 ft.lbs | 1670 N.m 1232 ft.lbs |
Low Gear Rated of Torque | 6000 N.m | 6000 N.m | 9000 N.m |
High Gear Rated of Speed | 4400 ft.lbs 85 RPM | 4400 ft.lbs 85 RPM | 6630 ft.lbs 81 RPM |
Low Gear Rated of Speed | 20 RPM | 23 RPM | 15 RPM |
Rated Operation Pressure | 11 Mpa 1600 PSI | 12 Mpa 1740 PSI | 12 Mpa 1740 PSI |
Rated Flow | 100 LPM 26 GPM | 100 LPM 26 GPM | 100 LPM 26 GPM |
Dimension:L*W*H | 750*500*600 29.5”*19.7”*23.6” | 900*515*710 35.4”*20.3”*28” | 900*570*600 35.4”*22.4”*23.6” |
Weight | 220 kg 485 lbs | 304 kg 670 lbs | 260 kg 620 lbs |
